Sorry about that guys, been a busy couple of days! I just did a quick sketch of the bed rack. Kind of in a rush, it's party season here in New Orleans.
Vehicle: 2007 GMC Sierra 1500
Rack type: Bed Rack
Not sure on a load rating yet, but I plan on using it for a CVT, Maxtrax, 4g rotopax, and maybe a few other items.
Now I have a wilco tire gate on my rig and it's made of 2" OD steel tube. I'd like to keep the bold (thicker) parts of my sketch two inch pipe just to match.
Now the thin lines in the sketch I was thinking 1.25" pipe. (Again, sorry for the inconvenience of a quick sketch)
I'm choosing to go with steel pipe. A little bending , welding, and a couple hours of free time(if I ever get any) and I'll be posting pictures of the finished product
